| B | E |
| Metal Series | Plastic Series |
.
| A | L | P |
| Flush Push button | Extended Push button | Push button (Cover) |
| W | D | J |
| Push button(Illuminated) | Selector Switch (Short-handle) | Selector Switch (Long-handle) |
| G | E | Z |
| Key-operated | Contact Block | Contact Block+Holder |
| B | C | R |
| Mushroom push buttonΦ30 | Mushroom push buttonΦ40 | Mushroom push buttonΦ60 |
| S4 | S5 | S6 |
| Emergency Stop Push button (Twist ReleaseΦ30) | Emergency Stop Push button (Twist ReleaseΦ40) | Emergency Stop Push button (Twist ReleaseΦ60) |
| T | V | |
| Emergency Stop Push button（Pull Release） | Pilot Light |
.Color
| 1 | 2 | 3 | 4 | 5 | 6 |
| White | Black | Green | Red | Yellow | Blue |
.Selector switch BD BJ BG
| 2 | 3 | 4 |
| 2-position (Maintained) | 3-position (Maintained) | 2-position (Momentary,R to L) |
| 5 | 6 | 7 |
| 3-position(Momentary R toC&l to C) | 3-position (Momentary,R to L) | 3-position (Momentary,L to C) |
.Contact Block
| 1 | 2 | 3 | 4 | 5 |
| 1NO | 1NC | 2NO | 2NC | 1NO+1NC |
Working Environment Main Technical Data
| Working environment temperature | -25~+70°C |
| Storage temperature | -40~+70°C |
| Class of pollution | Class3 |
| Limit height | ≤2000M |
| Standard | EN60947-1,GB14048.5 |
| Rated insulation voltage | 600V |
| Rated thermal current | 10A |
| Switch rating | AC-15 Ue :380V/250V , Ie=4.5A DC-15 Ue :220V/110V , Ie=0.6A |
| Contact resistance | ≤50mA |
| Recommended torque | 0.9Nm |
| Connectable area | （min)1X0.5mm2（Max)2X1.5mm2（or)1X2.5mm2 |
| Mechanical life | Push button≥300X104 times ,Selector switch ≥1004times |
| Emergency Stop Push button | ≥30X104times; |
| Electrical life | ≥30X104times; |
| Limit voltage (Lamp) | 0.8Ue≤U≤1.15Ue |
