GXB2-BL41 High Quality 1NO Momentary Extended Push Button With Red Round Shape Head And Spring Return

Product Name : Extended Push Button
Head Shape : Round
Mounting Hole Size: 22MM
Switch Value: Ith: 10A, UI: 600V
Color Of The Head : Red
Other Colors Of The Head : White/Black/Green/Yellow/Blue
Action Of The Head : Momentary
Normal Contact Pattern : 1NO
Material : Metal
Certification: CE
Place Of Origin : Zhejiang, China
Available equipment: Elevators, charging piles, automation equipment, motor vehicles, yachts, access control, automatic guided vehicles, lathes, lifts, lawn mowers

Share to:

GXB2-BL41

①: GXB2 Series

②: BL: Extended Push Button(Momentary)

③:Head Color : 1- White ; 2- Black ; 3- Green; 4- Red; 5 -Yellow; 6- Blue

④Contact Type : 1-1NO; 2-1NC; 3-2NO; 4-2NC ; 5-1NO+1NC

MAIN TECHNICAL DATA

Rated insulation voltage :600V

Rated thermal current:10A

Switch rating:AC-15 Ue:380V/250V, le=4.5A;DC-13Ue:220V/110V,le=0.6A

Contact resistance:≤50mA

Recommended torque :0.9Nm

Connectable area:min 1×0.5mm2,Max 2×1.5mm20r 1×2.5mm2

Mechanical life:Push button≥300×104 times;Selector Switch≥1004times

Emergency Stop Push button≥30×104 times

Electrical life:≥30×104 times

Limit voltage(lamp):0.8Ue≤U≤1.15Ue

Working Environment

Working environment temperature:-25~+70℃

Storage temperature:-40~+70℃

Class of pollution :3level

Protection grade:IP40/IP65/IP66

Limit height:≤2000m

Standard:EN 60947-1,GB14048.5

PARAMETRIC DIAGRAM

GXB2-BL41(1)
